有原厂说明书！
Specifications(技术参数):
Power Output
200Wrms per channel continuous both channels driven into 8Ω
330Wrms per channel continuous into 4Ω
from 20Hz to 20kHz at no more
than 0.01% Total Harmonic Distortion.
Total Harmonic Distortion(失真度).................................... 0.01%
Amplifier Saturation.......................> 550W per channel into 8Ω
Voltage Swing (输出电压)............................... 155Vp-p per channel
Current Output(输出电流)
Instantaneous peak ............................. 21A per channel
Uncompensated Bandwidth (带宽)......................0.1dB from 10Hz-300kHz
Phase Response(相移)................................+1° at 20Hz -2° at 20kHz
Hum and Noise (信噪比) .................. 100dB below rated output 20Hz-20kHz
Damping Factor(阻尼系数)........................... 400-1000
Input Impedance(输入阻抗) .................................... 47kΩ
Driver Stage(推动级) ................................Class A
Output Devices (放大级).................... Extended Class AB
